| 种类 | 插头/插座 |
|---|---|
| 工作频率 | 高频 |
| 应用范围 | 电脑 |
| 接口类型 | RJ45(水晶头) |
| 形状 | 矩形 |
| 制作工艺 | 熔接 |
| 加工定制 | 是 |
| 特性 | 变压 |
| 接触件材质 | 铜合金 |
| 品牌 | 华联威 |
| 型号 | RJ45+双层USB 无灯 |
NOTES:
1.MATERIAL:
1.1 Housing:thermoplastic plastics
1.2 terminals:Copper Alloy
Gold plated in contact area:
Tin plated in termination
Nickel Plated overall
1.3 Shell:Steel&Copper Alloy
Nickel Plated overall
2.ELECTRICAL CHARACTERISTICS:
2.1 Rating Current :1 Ampere
2.2 Rating Voltage :125 V Max
2.3 Contact Resistance:40 Milli ohms
2.4 Insulation Resistance:500 Mega ohms Min.
3.MECHANICAL CHARACTERISTICS:
3.1 Connector Mating force：35N MAX(3.57Kgf)
4.ENVIRonMENT CHARACTERISTICS:
4.1 Operating temperature:-40℃ to +85℃
4.2 Storage temperature:-40℃ to +85℃
